All standards are only available as Printable Download Format (PDF) downloads or electronic files. You will be able to download immediately after approved purchase. Each PDF is stamped with your company name and transaction number. You may distribute them only within your company.
Employees of VITA Member companies do NOT need to purchase standards from this online store, they may download from the VITA website. Confirm your company membership before purchasing. If your company is an active member and you do not have an account, you will need to register with VITA before you can download standards.
ANSI/VITA 42.3-2020, XMC PCI Express Protocol Layer Std. SKU: AV42.3-2020
XMC PCI Express Protocol Layer: This standard defines the implementation of PCI Express on VITA 42.0, XMC.
$50.00
XMC PCI Express Protocol Layer: This standard defines the implementation of PCI Express on VITA 42.0, XMC.
This edition revised bit positions and lengths to allow for encodings for PCIe speeds of Gen 3 to Gen 6. Table 5-4 from the VITA 42 standard was added to Sections 4.3.5 and 4.4.5 to address P16 pin definitions. Minor editorial changes to bring in line with current practice.
